Overview
Current, voltage and power always in view
Measuring voltage 0 - 40 V
Current measuring range -20 to +20 A
H-Tronic LM 800 Power meter Component 9 V DC, 12 V DC
Product description
Description
This power measurement module is particularly convincing due to its wide range of possible applications. It displays the measured values for current, voltage and power simultaneously on a blue illuminated, two-line LC display. The current measurement is galvanically isolated. Currents in the range -20 to +20 A can be measured. The Panel-Meter is therefore ideally suited for use in power supply units, chargers and solar systems - especially for testing electric flight, but also for ship models, model cars and other electric drives or direct current consumers. The determination of the information required for successful operation or for the optimization of flight and driving behavior or other DC motors is simplified by this powerful and at the same time handy device. The device is connected between the battery and the motor controller/controller and measures the DC voltage and DC current of the drive. The current input power of the drive is calculated in watts from the data obtained in this way.
Keywords
4260003173316, H-Tronic, 1190012, LM 800
