Independent switching point between a mains parallel production system and the public network
Use in accordance with Cei 0-21, VDE-AR-N 4105, BDEW directive, C 10/11, G 83/2, DIN V VDE V 0126-1-1
Universal for generating plants for safe power decoupling
Universal measuring relay for the realization of a network and system protection for a wide range of cases and countries. Simple start-up through default basic programs for country-specific standards and guidelines application area: BHKWs, wind turbines, water power plants, photovoltaic systems.
Flying Ehlers Safety · Monitoring of the connected Dome Switch (can be configured: NC/NO/off) · The island grid detection df/dt (ROCOF) · Interface RS-485 (software update) · Simulation function to determine the switch-off time · Test button for tripping circuit · Available of the last 300 network faults with time stamp/real-time clock · Permanent monitoring of the train and outer conductor voltage · Separate Zuschaltbedingungen after a threshold violation · Test button for tripping circuit ·
Remote Shutdown via round control signal receiver · Language selection (English, German, Italian) · Backlit graphic display · Password protection for device setting · Sealable Housing · Signal relay 2 x 1 changeover contact 5 A/230 V.
04016138813470, Bender, B93010045, LINETRAXX® VMD460, NA-protection
