B-SAFETY BR 554 030 Escape route lighting Ceiling recess-mount

Overview

Protection type IP40
Auto-test function
Rechargeable battery with an operation duration of 3 hours.

Description

Exclusive LED-disc light in modern design, for application in offices, public buildings, administrative buildings, schools and hotels. As a single battery discs-emergency light with auto-test function, signalling via 1 x multi-colored LED, including test button, according to DIN EN 60598-1, DIN EN 60598-2-22 and DIN EN 1838 for systems in accordance with DIN VDE 0108/10.89 to separate operation.

Characteristics

Continuous and standby switching · Permissible ambient temperature: 5 - 35°C · Lamp including 24x LED · NI-MH rechargeable battery 4.8 V/800 mAh · Pictogram disc: According to DIN ISO 7010 · Hole installation measure 333 x 90 x 61 mm

Information

Exact dimensions, please refer to the data sheet.

Delivery content

• Emergency light
• Standard set of information signs (TYPE A = emergency exit, TYPE B = escape route to the right, TYPE C = escape route left)
• Ceiling-mounted frame
• User manual.
