Overview
Material housing: Aluminium
LCD display 17 mm
Input type: Analogue input 4-20 mA
Housing design: Field housing
Approval: Non-explosive area
Endress+Hauser RIA15-AAB1 RIA15 Display 1 pc(s)
CHF 303.05
VAT included
plus
Delivery time:
3-4 days
available from 02/03/2026
30 days free return shipment
CHF 303.05
VAT included
plus
Product description
Description
The loop-fed RIA15 process indicator displays 4 to 20 mA measured values or optionally up to four HART® process variables of a sensor in all sectors. The RIA15 has a 5 digit measuring value display with 17 mm digit height with dimension, bar graph and switchable background lighting and can be used as an on-site display in the control panel installation housing or in the field housing.
Characteristics
Simple configuration and parameter assignment on site with 3 buttons on front.
No external power supply required, the device is supplied directly from the current loop.
Perfect solution for measurement points that are difficult to access, especially in case of long wiring distances/ voltage drop
Queries up to 4 different measured values in an ongoing process and displays them (via HART protocol).
Keywords
Endress+Hauser, RIA15-AAB1, RIA15, meter accessories, meter replacement, meter spare part
