Overview
(5) Gigabit RJ45 ports with passive PoE support
(1) Gigabit SFP port for backhaul applications
Ports configurable for line rate, Layer 2 switching
Ubiquiti Networks ER-X-SFP LAN router
Product description
Description
Ubiquiti Networks ER-X-SFP. Ethernet LAN data transfer rates: 10.100.1000 Mbit/s. Product color: Black
Characteristics
130 kpps for 64-byte packets · 1 Gbps for 1518-byte packets · Dimensions 142 x 75 x 23 mm (5.59 x 2.95 x 0.91") · Weight 215 g (7.58 oz) Max. power consumption 5W · Max. Total PoE output 50W @ 24V · PoE output passive 24V (pins 4, 5+; 7, 8-) · 24VDC current input, 2.5A power supply unit (included in the delivery) · Power supply External AC/DC adapter · Supported voltage range 9 to 26VDC · Reset button · LED power, connection/activity (6), PoE (5) · Dual-core processor 880 MHz, MIPS1004Kc · SYSTEM MEMORY 256 MB DDR3-RAM · Code storage 256 MB NAND · Wall mounting Yes · ESD/EMP protection air: ± 24 kV, contact: ± 24 kV, contact: ± 24 kV · Operating temperature -10 to 45° C (14 to 113° F) · Operating humidity 10 to 90% non-condensing · Network interfaces · Data/PoE output connector (5) 10/100/1000 RJ45 connectors · Data connection (1) 100/1000 SFP connection · PoE with 24VDC power supply · PoE output voltage range 22-24VDC · Max. PoE Watt power per · Data/PoE output connector · 12W (24V) · Max. PoE power combined · (All 5 data ports) · 50 W · PoE method Passive
