Hensel 61000734 KV 1504 Switchboard cabinet Content 1 pc(s)

Hensel 61000734 KV 1504 Switchboard cabinet Content 1 pc(s)

Hensel 61000734 KV 1504 Switchboard cabinet Content 1 pc(s)

price alarm

An error has occurred.

Desired price*

warranty period

Email address * Please enter a valid email address

Price alarm is activated! We will send you an e-mail as soon as your desired price has been reached.

CHF 24.10

VAT included

plus

piece

in stock

Delivery time: 4-6 days

Hensel 61000734 KV 1504 Switchboard cabinet Content 1 pc(s)

CHF 24.10

VAT included

plus

One article is not enough for you and you want to save money?

from 3 piece:	CHF 23.85	1,0% savings
from 5 piece:	CHF 23.61	2,0% savings
from 10 piece:	CHF 23.37	3,0% savings

Product description

Overview

4.5 division units: 1 x 4.5 x 18 mm
1-row
The PE/N number x cross-section 2 x 25 mm², 4 x 4 mm² Cu, FIXCONNECT® plug-in terminal technology

Description

Small distributor KV 1504

Characteristics

For the installation of devices with snap-on mounting on DIN rail, top hat 35 mm
With transparent cover, sealable
Lock for door and plombierset see accessories
With cable entry panel
The cut-out device removable
With integrated, elastic sealing membranes for cable entry
Protection class IP 54
Color: gray, RAL 7035
Rated insulation voltage Ui = 400V a.c.
Power output capacity Pde = 12 W at 30K according to EN 60670-24

Keywords

04012591107057, Hensel, 61000734, KV 1504, switchboard cabinet, distribution cabinet
