Overview
Output /
Adjustable
Power
Active PFC
Protection class: IP20
Suitable for installation in furniture
MW Mean Well PWM-90-24 LED transformer Constant voltage 90 W 0 - 3.75 A 24 V DC dimmable, PFC circuit, Surge protection 1 pc(s)
Image is similar
Product description
Description
Universal input · Plastic enclosure IP67 · Overload protection, pulsing hiccup shutdown, auto recovery · Protections: short circuit/over load/over voltage · Built-in active PFC function · Suitable for LED lighting and moving sign applications · PWM output voltage · dimming function (external voltage 1...10V DC, PWM) · EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13
Characteristics
Universal input · Overload protection through current limitation (Hiccup), auto recovery · Protected against short circuit, overload, over voltage · Built-in PFC circuit · IP67 · For LED lighting applications · PWM output voltage · Dimmable design (external voltage 1...10 V DC, PWM) · EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-12
Information
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
