Image is similar
Description
Installation contactor for 35 mm rail, 2 NC contacts and 2 NO contacts for 40 A / 440 V AC, contact material AgSnO2, max. inrush current 176 A - 5 ms, max. switching power at 230 V AC: AC1-AC-7a: 16 kVA, rated current AC3-AC7b 22 A, glow and halogen lamps 4000 W, fluorescent lamps with EVG 1500 W, Fluorescent lamps-uncompressed 1500 W, energy saving lamps 1000 W, LED (230 V AC) 1000 W, NV-halogen lamps or LED with EVG 1000 W, NV-halogen lamps or LED with KVG 1500 W. Coil 24 V AC/DC, width 53.5 mm, mechanical switching position display, relay protection type: IP 20
