Length 30 mmDiameter 1.2 mmOrange coloring for easier insertion of the fiberStable steel pin integrated as kink protectionEN 50411-3-3 compliantCan be used with common crimp-splice protection holdersTransparent for easy visual control of the splice with a color laserSuitable for fiber diameters up to 250 µm (primary coating)
The NetPeppers shrink splice protection guarantees a secure protection against external influences such as moisture or mechanical stress. The integrated steel pin provides even better protection against bending than the crimp splice protector. The orange color helps to insert the fiber into the sleeve opening without shielding the light from a red light source (VFL) during troubleshooting. The sleeves fulfill the requirements of the standard EN 50411-3-3. The micro-splice protection sleeve with a diameter of only 1.2 mm can be inserted into common splice protection holders for crimp-splice protection sleeves - a special holder is not necessary. Suitable for use with any conventional fusion coil furnace, up to a fiber diameter of 250 µm (primary coating).
Heat shrink furnace required
00305394487155, NetPeppers, NP-FS-PROTECT-S-12-30, PROTECT-S-12-30
