Navilock NL-8022MU GPS receiver White 1 pc(s)

Overview

Processes signals from up to 72 satellites simultaneously
u-blox 8 UBX-M8030-KT chipset
IPX7 Protection class
Auto Baud Rate up to 115200 bps

Description

The USB 2.0 Multi GNSS receiver with the u-blox 8 chipset has a built-in active antenna. In combination with a notebook and the corresponding navigation software, navigation is possible. The NL-8022MU GNSS receiver was specially developed for mounting on white surfaces (boat, motorhome, bus, etc.). It blends inconspicuously into the vehicle concept thanks to the white housing.

Characteristics

Connection: USB 2.0 Type-A connector - Chipset: u-blox 8 UBX-M8030-KT - Frequency: GPS: L1, 1575.4200 MHz; GLONASS: L1, 1602.5625 - 1615.5000 MHz; BEIDOU COMPASS: B1, 1561.0980 MHz; GALILEO: E1, 1575.4200 MHz; QZSS: L1, 1575.4200 MHz - Processes signals from up to 72 satellites simultaneously - Supports AssistNow online / offline, SBAS (WAAS, EGNOS, QZSS and MSAS) - Supports NMEA 0183 protocols: GGA, GSA, GSV, RMC, VTG - Auto baud rate up to 115200 bps - Update rate: simple GNSS: 18 Hz (z. B. GPS solo); multiple GNSS: 10 Hz (e.g. GPS+GLONASS) - Sensitivity max. -167 dBm - IPX7 Protection class - Operating temperature: -20 °C ~ 60 °C - Power supply: 5 V DC - Power consumption: max. 45 mA - Cold start in approx. 26 seconds - Hot start in approx. 1 second - Position accuracy: 2.5 m CEP (Circular Error Probable) and 2 m CEP with SBAS - Cable length: approx. 4.5 m.

Delivery content

• Navilock NL-8022MU
• fixing material: nut and washer stainless steel
• Navilock Support CD incl. driver and manual.

Requirements

PC or notebook with a free USB type A port + Windows Vista/7/8/8.1/10, Linux Kernel 2.6
