SIMATIC S7-200 is easy: programming software with Windows user interface
instructions for quick access to PLC technology
easy installation onto a top hat profile rail
SIMATIC S7-200 is compact: e.g. CPU 222: (W x H x D) 90 x 80 x 62 mm
own S7-200 net with PPI protocol
freely programmable interface.
This product is part of the Modicon TM5 series, a high-performance and secure modular IP20 I/O system. This analog safety input module offers 4 secure thermocouple inputs, PT100/PT1000 inputs and a resolution of 24 bit. There is a 500 V AC insulation between the channel and the bus. In conjunction with the TM5CSLC safety controller, this safety module offers decentralized security solutions on the Sercos bus up to SIL 3, Cat. 4, PL e, SIL CL3. It possesses 2 LEDs for the power supply, 2 LEDs for the safety status and 20 LEDs for signaling the input status. It is equipped with two wires for the electrical connection. The case color is red. It weighs 0.066 kg. It is 75 mm deep, 25 mm wide and 99 mm high. The Modicon TM5 meets the typical requirements of production and packaging machines as well as material transport and assembly systems. This product is certified according to GOST-R, C-Tick, cULus and CSA. It complies with the standards IEC 61131-2, UL 508, CSA C22.2 No. 213 and CSA C22.2 No. 142. It is compatible with the Modicon TM5CSLC safety controller. The installation is done by mounting on a 35 mm DIN rail. This modular IO system enables a flexible and scalable configuration of remote or distributed IO islands by connecting with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
