Overview
Laser category: 1
Laserfuchs Plumb dot laser
CHF 15.45
VAT included
plus
Delivery time:
3-4 days
available from 28/08/2026
30 days free return shipment
CHF 15.45
VAT included
plus
Product description
Characteristics
Point laser, red, 650nm, 0.4mW, laser class 1, Focus 5m, 3-4.5V, 15x67mm, battery-operated
The type LFD650-0.4-4.5(15x67) is a point laser for projection of a red laser point. The laser module emits 650nm wavelength radiation. The module contains 2 button cells (LR44) - included in the delivery. With this, a wireless operation is possible over several hours. The laser has a very compact design (15x67mm). The laser module LFD650-0.4-4.5(15x67) has a fixed pre-set optics and can be used excellently in light barriers, leveling systems or pointer applications. Typical usage areas are low-cost applications. This module falls into the laser class 1.
Latch switch: Press the switch at the end of the laser module once and the laser is permanently switched on. Repeated operation switches off the laser again.
Emission characteristics: Elliptical dot, dot size 4..6mm
Optical power: 0.4mW (laser class 1); focus: 5m
Compact design: 15x67mm; axis deviation up to 3.0°
For presentations, for positioning, for light barriers and many other applications in industry, trade, hobby and the show sector.
Two LR44 batteries are included in the delivery.
Keywords
Laserfuchs, 70112573, LFD650-0.4-4.5(15x67), laser, laser module, laser technology
