Overview
High-quality 15x15mm button
Adjustable RGB LED background lighting
Replaceable/printable inner part
TinkerForge 282 LED module Suitable for (single board PCs) TinkerForge 1 pc(s)
Product description
Description
The RGB LED Bricklet is equipped with a button whose background lighting can be controlled by software. The Bricklet expands Bricks.
The status of the button (pressed, not pressed) can be read out and the color of the LED can be controlled. The red, green and blue portion of the LED can be controlled with 8 bit resolution.
A white inner part is located under the key cap. This inner part can be replaced by its own printed inner part of the paper. Thus, for example, the button can be labeled with an arrow or similar.
In order not to have to constantly check the status of the button (pollen), events can also be used.
The RGB LED Button Bricklet has a 7-pin Bricklet plug and is connected with a 7p-10p Bricklet cable with a brick.
Characteristics
Power consumption (LEDs off): 31mW
(6.2mA at 5V) Power consumption (LEDs on): 207mW (41.4mA at 5V)
LED resolution: 8 bits per channel
Deposit size (labeling): 14 x 14mm
button size: 15 x 15mm
Cap size: 17.4 x 17.4mm
