KATHREIN

Kathrein EBC 13 SAT splitter 3-way 5 - 2400 MHz

Kabelweiche von Kathrein mit drei Anschlüssen, die mit 'OUT', 'OUT' und 'IN' gekennzeichnet sind. Frequenzbereich von 5-2400 MHz.

Remote feed-compatible

Delivery time: 3-4 days

Kathrein VWS 04 SAT amplifier

An electronic component labeled 'KATHREIN', model 'VWS 04', supporting frequencies from 5-862 MHz and 950-2150 MHz, maximum 400 mA.

Targeted gain: The amplifier is used primarily to amplify the satellite ZF in the frequency range from 950 to 2150 MHz. The amplification is between 14 and 17 dB and shows an increase in amplification as the frequency increases.
Terrestrial Bypass: The device has a passive bypass for the terrestrial range (5 to 862 MHz), which means that this frequency range is passed through unchanged.

Delivery time: 3-4 days

Kathrein ZTS 48sw Mast sealing set Suitable for pole Ø (max.): 48 mm Black

Roof flashing kit with a main vent pipe cover, screws, fixing brackets, and additional fittings for installation.

High stability: Suitable for fixing masts with a permissible bending torque of up to 1650 Nm – for maximum wind load safety.
Complete set: Contains all mounting and sealing parts, including mast cover ZTC 08, cover collar, aluminum roof panel, mast bracket, mast bracket and wood screws.

Delivery time: 3-4 days

Kathrein EXR 25516 SAT multiswitch Inputs (multiswitches): 5 (4 SAT/1 terrestrial) No. of participants: 16 Standby mode

Satellite multiswitch 'KATHREIN EXR 25516' with multiple input and output ports, labeled for high, low, and terrestrial frequencies.

High capacity and expandability: the multi-switch can cascade. It serves to distribute four satellite levels and terrestrial signals to a total of 16 subscriber connections. Up to six devices can be cascaded for plant expansion.
High signal separation: The multi-switch ensures high decoupling between the outputs. The decoupling of the trunk is 40 dB, while the uncoupling achieves horizontal to vertical 25 dB.

Delivery time: 3-4 days

Kathrein ERA 12 Terminator

A small, metallic cylindrical component with a pointed tip and a long, thin rod extending from the opposite end.

Optimumantenna sockets : Terminates unused outputs of distributors, feeders and signal quality at 75 Ω to effectively prevent disturbing signal reflections and noise.
DC separation (DC voltage decoupling): Has direct voltage decoupling, WAS is essential for safe operation in remote-fed satellite/BK systems.

Delivery time: 3-4 days

Kathrein 63020001 eMobility charging cable 7.5 m

Kathrein 63020001 eMobility charging cable 7.5 m

High mechanical strength
halogen-free, flame resistant
Very good cold flexibility

Currently not available

Kathrein Antennas, SAT Cable 0.80 m

Two coaxial cables with orange sealing rings and metallic connectors, commonly used for TV or satellite connections.

For connection and connection with SAT-ZF distribution systems, patch fields, multi-switches, etc.
Completely mounted with straight, high-quality F-plugs (F-Quick) made of brass (coating white bronze), color coding red
Shielding 105 dB, class A+

Delivery time: 3-4 days

Kathrein ZAS 60 SAT wall mount Projection distance: 17.5 cm Suitable for dish size: Ø 75 cm

Metal wall-mount bracket with an L-shaped design, featuring a round tube extending outward. Used for securing items like satellite dishes.

Delivery time: 3-4 days

Kathrein ESE 10 Antenna socket BK, SAT, TV, FM Screw fastening, Flush mount Non-terminated

Coaxial socket outlet featuring 'Kathrein' branding. Ports labeled 'TV' (5-2400 MHz, 10 dB) and 'R' (5-2400 MHz, 11 dB). Central 'ESE 10' label indicates 3 dB signal loss.

Broadband signal processing: The box is designed for an extremely wide frequency range from 4 to 2400 MHz Ideal, making it suitable for use in modern broadband (BK), GA (shared) and SAT home distribution systems.
Low transmission loss: It offers low transmission loss values, e.g. only 2.4 dB in the VHF/UHF range, WAS maintains signal quality in loop-through systems (series connection).

Delivery time: 3-4 days

Kathrein EXR 2558 SAT cascade multiswitch Inputs (multiswitches): 5 (4 SAT/1 terrestrial) No. of participants: 8

Multischalter von Kathrein, Modell 'EXR 2558'. Verfügt über zahlreiche Eingänge und Ausgänge für Satelliten- und terrestrische Signale.

Multi-switch 5 on 4, Continuity, for system expansion to four connections
It can be cascaded up to eight EXR 2554/2558
For indoor installation

Currently not available

Kathrein EXD 1532 SAT multiswitch Inputs (multiswitches): 5 (4 SAT/1 terrestrial) No. of participants: 32 Standby mode

Unicable sat-matrix 4 modes
Inputs 1 × 5–862 MHz and 4 x 300–2350 MHz
2 outputs for up to 32 subscribers

Delivery time: 3-4 days

Kathrein EMU 290 Connector 5 - 2150 MHz

Eight empty incandescent light bulb sockets arranged in a straight line on a rectangular white base.

9-fold low-loss connection: The connector carries 8 SAT-ZF levels and 1 terrestrial signal with a minimum transmission loss of ≤0.3 dB.
Optimal system integration: Specially developed for the smooth cascading of Kathrein-components of the EXR 29xx multi-switch series and VWS 29xx distribution power amplifier.

Delivery time: 3-4 days
